LumaDent ErgoPrism

LumaDent ErgoPrism

  You’ll need to LOGIN to place an order.

If you don’t already have an account, you can create one HERE. It will take about a minute and you’ll be able to place your order straight away – There’s no waiting, phone calls or arduous paperwork required!
Brand: LumaDent
Category:  Optical
Collections:  Loupes

ErgoPrism Loupes enable you to practice in an upright, relaxed position that can alleviate neck and back pain. Featuring a compact, ergonomic design, powerful magnification, a wide field of view and adjustable focus.

Traditional loupes are great, but they only do half the job. Our loupes take your health and comfort to the next level, allowing you to work without straining your neck or back. Our loupes will allow you to practice in a neutral, relaxed, upright position. This is a benefit that traditional-style loupes just can't contend with.

Our selection of deflection prism loupes allows for stress-free parallel viewing. Eye fatigue is minimised by looking straight ahead with a 0º pupil angle – the work is left up to the prisms to focus, deflect your view downwards, and rotate it towards the focal point in your surgical field. Conventional Galilean or Keplerian loupes achieve a focal point by leaving the focusing and converging pupil angles up to your eye muscles.

*Light not included.

3.0x MAGNIFICATION

  • Deflection Custom up to -40º
  • Pupil tracking 0º
  • MPD 27-37mm
  • FOV 89mm
  • DOF 76mm
  • Weight 67.8g
  • Exit pupil diameter 6.4mm
  • Lenses 6 - 3 Objective + 3 Occular
  • Working distance Custom 350-700mm



4.0x MAGNIFICATION

  • Deflection Custom up to -40º
  • Pupil tracking 0º
  • MPD 27-37mm
  • FOV 75mm
  • DOF 51mm
  • Weight 68.2g
  • Exit pupil diameter 6.4mm
  • Lenses 6 - 3 Objective + 3 Occular
  • Working distance Custom 350-700mm



5.0x MAGNIFICATION

  • Deflection Custom up to -40º
  • Pupil tracking 0º
  • MPD 27-37mm
  • FOV 65mm
  • DOF 51mm
  • Weight 69.2g
  • Exit pupil diameter 6.4mm
  • Lenses 5 - 2 Objective + 3 Occular
  • Working distance Custom 350-700mm

Q: Can I wear these loupes with prescription glasses?
A: No, you can't wear the ErgoPrism loupes over your prescription glasses, but you can

Q: How do I know which magnification is right for me?
A: If you're not sure which magnification is right for you, you can book a demo with our friendly state reps HERE

Q: How long does it take to receive my loupes after ordering?
A: As the loupes are customised and manufactured to each order from the US, you can expect to receive the loupes around 6-8 weeks after payment.

Q: Are these loupes compatible with LED headlights?
A: Yes, the ErgoPrism loupes are compatible with most LED headlights given you have the correct mount for the headlight.

Options:

Name SKU Price Stock Quantity
LumaDent ErgoPrism 3.0x ERGO033 $3,195.00 Instock
LumaDent ErgoPrism 4.0x ERGO043 $3,495.00 Instock
LumaDent ErgoPrism 5.0x ERGO050 $3,795.00 Instock
LumaDent ErgoPrism 6.0x ERGO060 $3,995.00 Instock
